Orquidea AI - 1.0v - Smart Humidity Controller

#include <Arduino.h>
// ============================================================
//  Orquidea IA v1.0  —  Servidor Web Local + LittleFS
//  Humidificador Inteligente com Dashboard Web + OLED
//  Histórico persistente de 7 dias em flash (LittleFS)
// ============================================================
//  ACESSO:
//    1. Abre o Monitor Série — o IP aparece no arranque
//    2. Abre esse IP no browser do telemóvel ou PC
//    3. Via VPN: acede ao mesmo IP da rede de casa
//
//  CONFIGURAÇÃO:
//    Substitui WIFI_SSID e WIFI_PASS abaixo com os teus dados.
// ============================================================

// ── Credenciais Wi-Fi ────────────────────────────────────────
#define WIFI_SSID  "O_Teu_WiFi"      // ← substitui
#define WIFI_PASS  "A_Tua_Password"  // ← substitui

#include <WiFi.h>
#include <ESPAsyncWebServer.h>
#include <AsyncTCP.h>
#include <ArduinoJson.h>
#include <DHT.h>
#include <Wire.h>
#include <Adafruit_GFX.h>
#include <Adafruit_SSD1306.h>
#include <LittleFS.h>
#include <time.h>

// ── Pinos ────────────────────────────────────────────────────
#define DHT_PIN        4
#define RELAY_PIN      26
#define WATER_SIG_PIN  32
#define WATER_PWR_PIN  27
#define OLED_SDA       21
#define OLED_SCL       22

// ── OLED ─────────────────────────────────────────────────────
#define SCREEN_WIDTH  128
#define SCREEN_HEIGHT  64
#define OLED_RESET     -1
#define OLED_ADDRESS  0x3C

// ── Histórico ─────────────────────────────────────────────────
// 1 ponto a cada 10 minutos = 144 pontos/dia × 7 dias = 1008 pontos
#define HISTORY_DAYS     7
#define HISTORY_INTERVAL_MS  600000UL   // 10 minutos em ms
#define DATA_DIR         "/data"

// ── Sensor de água ────────────────────────────────────────────

// Forward declarations

// Forward declarations
function downloadDay();
function downloadAll();

void mistOn();
void mistOff();
void updateTimeStrings();
float readWaterLevel();
void saveHistoryPoint(float t, float h);
String listAvailableDays();
String readDayHistory(const String& day);
void pruneOldFiles();
void broadcastState();
void onWsEvent(AsyncWebSocket *srv, AsyncWebSocketClient *client, AwsEventType type, void *arg, uint8_t *data, size_t len);
void readAndControl();
void showBootScreen();
void updateDisplay();
function showTab(name);
function initCharts(labels, temps, hums);
function loadAvailableDays();
function loadSelectedDay();
function connect();
function send(obj);
function toggleMist();
function sendTempMin(v);
function sendTempMax(v);
function sendHumMin(v);
function sendHumMax(v);

const int   RAW_EMPTY           = 0;
const int   RAW_FULL            = 3200;
const float WATER_LOW_THRESHOLD = 20.0f;
const float WATER_CRIT          = 10.0f;

Adafruit_SSD1306 display(SCREEN_WIDTH, SCREEN_HEIGHT, &Wire, OLED_RESET);

#define DHTTYPE DHT22
DHT dht(DHT_PIN, DHTTYPE);

// ── NTP ──────────────────────────────────────────────────────
#define NTP_SERVER  "pool.ntp.org"
#define TZ_PORTUGAL "WET0WEST,M3.5.0/1,M10.5.0"
char timeStr[9]  = "--:--:--";
char dateStr[11] = "--/--/----";
char dateKey[11] = "";   // "YYYY-MM-DD" — chave do ficheiro de hoje

// ── Servidor ─────────────────────────────────────────────────
AsyncWebServer server(80);
AsyncWebSocket ws("/ws");

// ── Estado ───────────────────────────────────────────────────
float humMin         = 60.0f;
float humMax         = 70.0f;
float tempMin        = 20.0f;
float tempMax        = 28.0f;
bool  manualOverride = false;
bool  mistRunning    = false;
bool  tempAlertLow   = false;
bool  tempAlertHigh  = false;
bool  waterAlertSent = false;
float lastTemp       = 0.0f;
float lastHumidity   = 0.0f;
float lastWater      = 0.0f;

// ── Temporizadores ───────────────────────────────────────────
unsigned long lastReadMs    = 0;
unsigned long lastOledMs    = 0;
unsigned long lastHistoryMs = 0;
const unsigned long READ_INTERVAL = 5000UL;
const unsigned long OLED_INTERVAL = 1000UL;

// ── Orquídea pixel art 32x32 (PROGMEM) ──────────────────────
static const unsigned char PROGMEM orchid_bmp[] = {
  0x00,0x00,0x00,0x00,
  0x00,0x01,0x80,0x00,
  0x00,0x03,0xC0,0x00,
  0x00,0x07,0xE0,0x00,
  0x00,0x0F,0xF0,0x00,
  0x00,0x1C,0x38,0x00,
  0x00,0x38,0x1C,0x00,
  0x00,0x70,0x0E,0x00,
  0x03,0xE0,0x07,0xC0,
  0x07,0xC0,0x03,0xE0,
  0x0F,0x80,0x01,0xF0,
  0x1F,0x00,0x00,0xF8,
  0x1E,0x03,0xC0,0x78,
  0x3C,0x07,0xE0,0x3C,
  0x38,0x0F,0xF0,0x1C,
  0x30,0x1F,0xF8,0x0C,
  0x30,0x1F,0xF8,0x0C,
  0x38,0x0F,0xF0,0x1C,
  0x3C,0x07,0xE0,0x3C,
  0x1E,0x03,0xC0,0x78,
  0x1F,0x00,0x00,0xF8,
  0x0F,0x80,0x01,0xF0,
  0x07,0xC0,0x03,0xE0,
  0x03,0xE0,0x07,0xC0,
  0x00,0x70,0x0E,0x00,
  0x00,0x38,0x1C,0x00,
  0x00,0x1C,0x38,0x00,
  0x00,0x0F,0xF0,0x00,
  0x00,0x07,0xE0,0x00,
  0x00,0x03,0xC0,0x00,
  0x00,0x01,0x80,0x00,
  0x00,0x00,0x00,0x00
};

// ── Relé ─────────────────────────────────────────────────────
void mistOn()  { digitalWrite(RELAY_PIN, LOW);  mistRunning = true;  }
void mistOff() { digitalWrite(RELAY_PIN, HIGH); mistRunning = false; }

// ── Hora NTP ─────────────────────────────────────────────────
void updateTimeStrings() {
  struct tm tinfo;
  if (!getLocalTime(&tinfo)) return;
  strftime(timeStr, sizeof(timeStr), "%H:%M:%S", &tinfo);
  strftime(dateStr, sizeof(dateStr), "%d/%m/%Y",  &tinfo);
  strftime(dateKey, sizeof(dateKey), "%Y-%m-%d",  &tinfo);
}

// ── Nível de água ─────────────────────────────────────────────
float readWaterLevel() {
  digitalWrite(WATER_PWR_PIN, HIGH);
  delay(10);
  int raw = analogRead(WATER_SIG_PIN);
  digitalWrite(WATER_PWR_PIN, LOW);
  float pct = ((float)(raw - RAW_EMPTY) / (float)(RAW_FULL - RAW_EMPTY)) * 100.0f;
  return constrain(pct, 0.0f, 100.0f);
}

// ── LittleFS: guardar ponto no CSV do dia ────────────────────
// Ficheiro: /data/YYYY-MM-DD.csv
// Formato linha: HH:MM,temp,hum
void saveHistoryPoint(float t, float h) {
  if (strlen(dateKey) == 0) return;
  char path[32];
  snprintf(path, sizeof(path), "%s/%s.csv", DATA_DIR, dateKey);
  File f = LittleFS.open(path, "a");
  if (!f) { Serial.printf("Erro ao abrir %s\n", path); return; }
  char line[32];
  snprintf(line, sizeof(line), "%s,%.1f,%.1f\n",
           timeStr[0] == '-' ? "--:--" : String(timeStr).substring(0,5).c_str(),
           t, h);
  f.print(line);
  f.close();
  Serial.printf("Histórico: %s → %.1fC  %.1f%%\n", path, t, h);
}

// ── LittleFS: listar dias disponíveis ────────────────────────
String listAvailableDays() {
  JsonDocument doc;
  JsonArray arr = doc.to<JsonArray>();
  File dir = LittleFS.open(DATA_DIR);
  if (dir && dir.isDirectory()) {
    File entry = dir.openNextFile();
    while (entry) {
      String name = entry.name();  // "YYYY-MM-DD.csv"
      if (name.endsWith(".csv")) {
        String day = name.substring(0, name.length() - 4);
        arr.add(day);
      }
      entry = dir.openNextFile();
    }
  }
  String out;
  serializeJson(doc, out);
  return out;
}

// ── LittleFS: ler CSV de um dia → JSON ───────────────────────
String readDayHistory(const String& day) {
  char path[32];
  snprintf(path, sizeof(path), "%s/%s.csv", DATA_DIR, day.c_str());
  JsonDocument doc;
  JsonArray labels = doc["labels"].to<JsonArray>();
  JsonArray temps  = doc["temps"].to<JsonArray>();
  JsonArray hums   = doc["hums"].to<JsonArray>();
  doc["day"] = day;

  if (!LittleFS.exists(path)) {
    doc["error"] = "Dia sem dados";
    String out; serializeJson(doc, out); return out;
  }
  File f = LittleFS.open(path, "r");
  if (!f) {
    doc["error"] = "Erro ao ler ficheiro";
    String out; serializeJson(doc, out); return out;
  }
  while (f.available()) {
    String line = f.readStringUntil('\n');
    line.trim();
    if (line.length() == 0) continue;
    int c1 = line.indexOf(',');
    int c2 = line.indexOf(',', c1 + 1);
    if (c1 < 0 || c2 < 0) continue;
    labels.add(line.substring(0, c1));
    temps.add(line.substring(c1 + 1, c2).toFloat());
    hums.add(line.substring(c2 + 1).toFloat());
  }
  f.close();
  String out; serializeJson(doc, out); return out;
}

// ── LittleFS: apagar ficheiros com mais de 7 dias ────────────
void pruneOldFiles() {
  struct tm tinfo;
  if (!getLocalTime(&tinfo)) return;
  File dir = LittleFS.open(DATA_DIR);
  if (!dir || !dir.isDirectory()) return;
  File entry = dir.openNextFile();
  while (entry) {
    String name = entry.name();  // "YYYY-MM-DD.csv"
    entry = dir.openNextFile();
    if (!name.endsWith(".csv")) continue;
    // Compara ano-mês-dia como string (formato ISO ordena corretamente)
    // Calcula data de 7 dias atrás
    time_t now = time(nullptr);
    now -= (time_t)(HISTORY_DAYS * 86400UL);
    struct tm old;
    localtime_r(&now, &old);
    char cutoff[11];
    strftime(cutoff, sizeof(cutoff), "%Y-%m-%d", &old);
    String day = name.substring(0, name.length() - 4);
    if (day < String(cutoff)) {
      char path[32];
      snprintf(path, sizeof(path), "%s/%s.csv", DATA_DIR, day.c_str());
      LittleFS.remove(path);
      Serial.printf("Removido histórico antigo: %s\n", path);
    }
  }
}

// ── Envia JSON de estado para todos os clientes WebSocket ─────
void broadcastState() {
  JsonDocument doc;
  doc["temp"]       = round(lastTemp     * 10.0f) / 10.0f;
  doc["hum"]        = round(lastHumidity * 10.0f) / 10.0f;
  doc["water"]      = (int)lastWater;
  doc["mist"]       = mistRunning;
  doc["manual"]     = manualOverride;
  doc["humMin"]     = (int)humMin;
  doc["humMax"]     = (int)humMax;
  doc["tempMin"]    = (int)tempMin;
  doc["tempMax"]    = (int)tempMax;
  doc["date"]       = dateStr;
  doc["time"]       = timeStr;
  doc["alertTemp"]  = (tempAlertLow || tempAlertHigh);
  doc["alertWater"] = waterAlertSent;
  doc["alertMsg"]   = tempAlertLow   ? "Temperatura abaixo do minimo!" :
                      tempAlertHigh  ? "Temperatura acima do maximo!"  :
                      waterAlertSent ? "Nivel de agua baixo!"          : "";
  String out;
  serializeJson(doc, out);
  ws.textAll(out);
}

// ── WebSocket: recebe comandos do browser ─────────────────────
void onWsEvent(AsyncWebSocket *srv, AsyncWebSocketClient *client,
               AwsEventType type, void *arg, uint8_t *data, size_t len) {
  if (type == WS_EVT_DATA) {
    data[len] = 0;
    JsonDocument doc;
    if (deserializeJson(doc, (char*)data) != DeserializationError::Ok) return;
    const char* cmd = doc["cmd"];
    if (!cmd) return;
    if (strcmp(cmd, "setMist") == 0) {
      bool on = doc["value"];
      manualOverride = on;
      if (on) mistOn(); else mistOff();
    } else if (strcmp(cmd, "setHumMin") == 0) {
      humMin = constrain((float)doc["value"], 30.0f, 95.0f);
      if (humMin >= humMax) humMin = humMax - 1.0f;
    } else if (strcmp(cmd, "setHumMax") == 0) {
      humMax = constrain((float)doc["value"], 30.0f, 95.0f);
      if (humMax <= humMin) humMax = humMin + 1.0f;
    } else if (strcmp(cmd, "setTempMin") == 0) {
      tempMin = constrain((float)doc["value"], 0.0f, 50.0f);
      if (tempMin >= tempMax) tempMin = tempMax - 1.0f;
      tempAlertLow = tempAlertHigh = false;
    } else if (strcmp(cmd, "setTempMax") == 0) {
      tempMax = constrain((float)doc["value"], 0.0f, 50.0f);
      if (tempMax <= tempMin) tempMax = tempMin + 1.0f;
      tempAlertLow = tempAlertHigh = false;
    }
    broadcastState();
  }
}

// ── Leitura e controlo principal ─────────────────────────────
void readAndControl() {
  float humidity    = dht.readHumidity();
  float temperature = dht.readTemperature();
  if (isnan(humidity) || isnan(temperature)) {
    Serial.println(F("Erro: falha na leitura do DHT22!"));
    return;
  }
  float waterPct = readWaterLevel();
  lastTemp     = temperature;
  lastHumidity = humidity;
  lastWater    = waterPct;
  Serial.printf("Temp: %.1f C  |  Hum: %.1f %%  |  Agua: %.0f %%\n",
                temperature, humidity, waterPct);

  // Alertas de temperatura
  if (temperature < tempMin) {
    if (!tempAlertLow) { tempAlertLow = true; tempAlertHigh = false;
      Serial.println(F("ALERTA: Temperatura abaixo do minimo!")); }
  } else if (temperature > tempMax) {
    if (!tempAlertHigh) { tempAlertHigh = true; tempAlertLow = false;
      Serial.println(F("ALERTA: Temperatura acima do maximo!")); }
  } else { tempAlertLow = tempAlertHigh = false; }

  // Alerta nível de água
  if (waterPct < WATER_LOW_THRESHOLD) {
    if (!waterAlertSent) { waterAlertSent = true;
      Serial.println(F("ALERTA: Nivel de agua baixo!")); }
    if (waterPct < WATER_CRIT && !manualOverride) mistOff();
  } else { waterAlertSent = false; }

  // Controlo automático
  if (!manualOverride) {
    if (humidity < humMin)      mistOn();
    else if (humidity > humMax) mistOff();
  }
  broadcastState();
}

// ── Ecrã de arranque ─────────────────────────────────────────
void showBootScreen() {
  display.clearDisplay();
  display.drawBitmap(2, 16, orchid_bmp, 32, 32, SSD1306_WHITE);
  display.setTextSize(1);
  display.setTextColor(SSD1306_WHITE);
  display.setCursor(40, 10);
  display.print(F("Orquidea IA"));
  display.setCursor(40, 22);
  display.print(F("v1.0"));
  display.drawLine(37, 8, 37, 50, SSD1306_WHITE);
  display.setCursor(40, 36);
  display.print(F("A ligar WiFi..."));
  display.display();
}

// ── Display principal ─────────────────────────────────────────
void updateDisplay() {
  updateTimeStrings();
  display.clearDisplay();
  display.setTextSize(1);
  display.setTextColor(SSD1306_WHITE);

  // Título + versão
  display.setCursor(2, 0);
  display.print(F("Orquidea IA"));
  display.setCursor(92, 0);
  display.print(F("v1.0"));
  display.drawLine(0, 9, 127, 9, SSD1306_WHITE);

  // Temperatura | gama
  display.setCursor(0, 12);
  display.print(F("Temp:"));
  display.setCursor(32, 12);
  display.print(lastTemp, 1);
  display.print(F(" C"));
  display.drawLine(79, 10, 79, 22, SSD1306_WHITE);
  display.setCursor(82, 12);
  display.print((int)tempMin); display.print(F("C-")); display.print((int)tempMax); display.print(F("C"));

  // Humidade | gama
  display.setCursor(0, 23);
  display.print(F("Hum: "));
  display.setCursor(32, 23);
  display.print(lastHumidity, 1);
  display.print(F(" %"));
  display.drawLine(79, 22, 79, 34, SSD1306_WHITE);
  display.setCursor(82, 23);
  display.print((int)humMin); display.print(F("%-")); display.print((int)humMax); display.print(F("%"));

  display.drawLine(0, 33, 127, 33, SSD1306_WHITE);

  // Nebulizador + nível água
  display.setCursor(0, 36);
  display.print(mistRunning ? F("NEBULIZ:ON ") : F("NEBULIZ:OFF"));
  display.setCursor(68, 36);
  display.print(F("H2O:"));
  int barW   = 34;
  int filled = constrain((int)((lastWater / 100.0f) * barW), 0, barW);
  display.drawRect(90, 36, barW + 2, 7, SSD1306_WHITE);
  display.fillRect(91, 37, filled, 5, SSD1306_WHITE);
  display.setCursor(68, 46);
  display.print(F("H2O:"));
  display.print((int)lastWater);
  display.print(F("%"));
  if (waterAlertSent) { display.setCursor(112, 46); display.print(F("!")); }

  display.drawLine(0, 54, 127, 54, SSD1306_WHITE);

  // Data / Hora
  display.setCursor(0, 56);
  display.print(dateStr);
  display.setCursor(74, 56);
  display.print(timeStr);

  display.display();
}

// ── Página HTML (PROGMEM) ────────────────────────────────────
static const char HTML_PAGE[] PROGMEM = R"rawhtml(
<!DOCTYPE html>
<html lang="pt">
<head>
<meta charset="UTF-8">
<meta name="viewport" content="width=device-width,initial-scale=1">
<title>Orquidea IA</title>
<script src="https://cdn.jsdelivr.net/npm/chart.js@4.4.0/dist/chart.umd.min.js"></script>
<style>
  :root{--green:#4caf50;--red:#f44336;--blue:#2196f3;--orange:#ff9800;--bg:#111;--card:#1e1e1e;--text:#eee;--sub:#aaa;}
  *{box-sizing:border-box;margin:0;padding:0;}
  body{font-family:'Segoe UI',sans-serif;background:var(--bg);color:var(--text);min-height:100vh;padding:12px;}
  h1{text-align:center;font-size:1.4rem;margin-bottom:4px;letter-spacing:1px;}
  .subtitle{text-align:center;color:var(--sub);font-size:.8rem;margin-bottom:14px;}
  .grid{display:grid;grid-template-columns:1fr 1fr;gap:10px;max-width:480px;margin:0 auto;}
  .card{background:var(--card);border-radius:12px;padding:14px;text-align:center;}
  .card.full{grid-column:1/-1;}
  .label{font-size:.7rem;color:var(--sub);text-transform:uppercase;letter-spacing:.5px;margin-bottom:4px;}
  .value{font-size:2rem;font-weight:700;}
  .unit{font-size:.9rem;color:var(--sub);}
  .range{font-size:.72rem;color:var(--sub);margin-top:2px;}
  .bar-bg{background:#333;border-radius:6px;height:10px;margin-top:8px;overflow:hidden;}
  .bar-fill{height:100%;border-radius:6px;background:var(--blue);transition:width .4s;}
  .badge{display:inline-block;padding:3px 10px;border-radius:20px;font-size:.75rem;font-weight:600;margin-top:6px;}
  .badge.on{background:#1b5e20;color:#a5d6a7;}
  .badge.off{background:#333;color:#aaa;}
  .controls{max-width:480px;margin:12px auto 0;}
  .ctrl-card{background:var(--card);border-radius:12px;padding:14px;margin-bottom:10px;}
  .ctrl-title{font-size:.8rem;color:var(--sub);text-transform:uppercase;margin-bottom:10px;letter-spacing:.5px;}
  .row{display:flex;align-items:center;justify-content:space-between;margin-bottom:8px;}
  .row label{font-size:.85rem;min-width:80px;}
  .row input[type=range]{flex:1;margin:0 10px;accent-color:var(--blue);}
  .row span{font-size:.85rem;min-width:36px;text-align:right;color:var(--blue);}
  .toggle-btn{width:100%;padding:12px;border:none;border-radius:8px;font-size:1rem;font-weight:600;cursor:pointer;transition:background .2s;margin-top:8px;}
  .toggle-btn.on{background:#1b5e20;color:#a5d6a7;}
  .toggle-btn.off{background:#333;color:#aaa;}
  .alert-banner{display:none;background:#b71c1c;color:#fff;border-radius:10px;padding:10px 14px;text-align:center;font-size:.85rem;margin:10px auto;max-width:480px;}
  .alert-banner.show{display:block;}
  .datetime{text-align:center;color:var(--sub);font-size:.78rem;margin-top:8px;margin-bottom:4px;}
  .dot{display:inline-block;width:8px;height:8px;border-radius:50%;margin-right:5px;}
  .dot.online{background:var(--green);}
  .dot.offline{background:var(--red);}
  .chart-card{background:var(--card);border-radius:12px;padding:14px;margin-bottom:10px;}
  .chart-title{font-size:.8rem;color:var(--sub);text-transform:uppercase;letter-spacing:.5px;margin-bottom:8px;}
  .chart-wrap{position:relative;height:160px;}
  .tab-row{display:flex;gap:6px;margin-bottom:10px;}
  .tab-btn{flex:1;padding:7px;border:none;border-radius:8px;font-size:.78rem;font-weight:600;cursor:pointer;background:#333;color:#aaa;transition:background .2s;}
  .tab-btn.active{background:var(--blue);color:#fff;}
  .section{max-width:480px;margin:0 auto;}
  /* Seletor de dia */
  .day-selector{display:flex;align-items:center;gap:8px;margin-bottom:12px;flex-wrap:wrap;}
  .day-selector label{font-size:.8rem;color:var(--sub);}
  .day-selector select{background:#2a2a2a;color:var(--text);border:1px solid #444;border-radius:6px;padding:5px 8px;font-size:.82rem;flex:1;}
  .day-selector button{background:var(--blue);color:#fff;border:none;border-radius:6px;padding:5px 12px;font-size:.82rem;cursor:pointer;}
  .hist-info{font-size:.75rem;color:var(--sub);margin-bottom:8px;text-align:center;}
</style>
</head>
<body>
<h1>🌸 Orquidea IA</h1>
<p class="subtitle"><span class="dot offline" id="wsdot"></span><span id="wsstatus">A ligar...</span></p>
<div id="alertBanner" class="alert-banner"></div>

<!-- TABS -->
<div class="section">
  <div class="tab-row">
    <button class="tab-btn active" onclick="showTab('dashboard')">📊 Dashboard</button>
    <button class="tab-btn" onclick="showTab('charts')">📈 Gráficos</button>
    <button class="tab-btn" onclick="showTab('settings')">⚙️ Ajustes</button>
  </div>
</div>

<!-- TAB: DASHBOARD -->
<div id="tab-dashboard">
  <div class="grid">
    <div class="card">
      <div class="label">Temperatura</div>
      <div class="value" id="temp">--</div>
      <div class="unit">°C</div>
      <div class="range" id="tempRange">-- a --</div>
    </div>
    <div class="card">
      <div class="label">Humidade</div>
      <div class="value" id="hum">--</div>
      <div class="unit">%</div>
      <div class="range" id="humRange">-- a --</div>
    </div>
    <div class="card full">
      <div class="label">Nível de Água</div>
      <div class="value" id="water">--</div><span class="unit">%</span>
      <div class="bar-bg"><div class="bar-fill" id="waterBar" style="width:0%"></div></div>
    </div>
    <div class="card full">
      <div class="label">Nebulizador</div>
      <div id="mistBadge" class="badge off">OFF</div>
      <button class="toggle-btn off" id="mistBtn" onclick="toggleMist()">Ligar Manual</button>
    </div>
  </div>
  <div class="datetime" id="datetime">--/--/---- --:--:--</div>
</div>

<!-- TAB: GRÁFICOS -->
<div id="tab-charts" style="display:none">
  <div class="section">
    <!-- Seletor de dia -->
    <div class="ctrl-card">
      <div class="ctrl-title">📅 Selecionar Dia</div>
      <div class="day-selector">
        <label>Dia:</label>
        <select id="daySelect"></select>
        <button onclick="loadSelectedDay()">Ver</button>
      </div>
      <div class="hist-info" id="histInfo">A carregar dias disponíveis...</div>
      <div style="display:flex;gap:8px;margin-top:10px;">
        <button onclick="downloadDay()" style="flex:1;padding:8px;background:#1565c0;color:#fff;border:none;border-radius:8px;font-size:.82rem;cursor:pointer;">⬇️ Descarregar Dia</button>
        <button onclick="downloadAll()" style="flex:1;padding:8px;background:#1b5e20;color:#fff;border:none;border-radius:8px;font-size:.82rem;cursor:pointer;">⬇️ Histórico Completo</button>
      </div>
    </div>
    <div class="chart-card">
      <div class="chart-title">🌡 Temperatura (°C)</div>
      <div class="chart-wrap"><canvas id="chartTemp"></canvas></div>
    </div>
    <div class="chart-card">
      <div class="chart-title">💧 Humidade (%)</div>
      <div class="chart-wrap"><canvas id="chartHum"></canvas></div>
    </div>
  </div>
</div>

<!-- TAB: AJUSTES -->
<div id="tab-settings" style="display:none">
  <div class="controls">
    <div class="ctrl-card">
      <div class="ctrl-title">🌡 Faixa de Temperatura</div>
      <div class="row">
        <label>Mínimo</label>
        <input type="range" id="tempMinSlider" min="0" max="50" value="20" oninput="sendTempMin(this.value)">
        <span id="tempMinVal">20°C</span>
      </div>
      <div class="row">
        <label>Máximo</label>
        <input type="range" id="tempMaxSlider" min="0" max="50" value="28" oninput="sendTempMax(this.value)">
        <span id="tempMaxVal">28°C</span>
      </div>
    </div>
    <div class="ctrl-card">
      <div class="ctrl-title">💧 Faixa de Humidade</div>
      <div class="row">
        <label>Mínimo</label>
        <input type="range" id="humMinSlider" min="30" max="95" value="60" oninput="sendHumMin(this.value)">
        <span id="humMinVal">60%</span>
      </div>
      <div class="row">
        <label>Máximo</label>
        <input type="range" id="humMaxSlider" min="30" max="95" value="70" oninput="sendHumMax(this.value)">
        <span id="humMaxVal">70%</span>
      </div>
    </div>
  </div>
</div>

<script>
// ── Tabs ──────────────────────────────────────────────────────
let chartsInitialized = false;
function showTab(name) {
  ['dashboard','charts','settings'].forEach(t => {
    document.getElementById('tab-'+t).style.display = (t===name)?'':'none';
  });
  document.querySelectorAll('.tab-btn').forEach((b,i) => {
    b.classList.toggle('active', ['dashboard','charts','settings'][i]===name);
  });
  if (name === 'charts' && !chartsInitialized) {
    chartsInitialized = true;
    loadAvailableDays();
  }
}

// ── Chart.js ──────────────────────────────────────────────────
const chartOpts = (color, unit) => ({
  responsive:true, maintainAspectRatio:false, animation:false,
  plugins:{
    legend:{display:false},
    tooltip:{callbacks:{label:ctx=>ctx.parsed.y.toFixed(1)+unit}}
  },
  scales:{
    x:{ticks:{color:'#aaa',font:{size:9},maxTicksLimit:10},grid:{color:'#2a2a2a'}},
    y:{ticks:{color:'#aaa',font:{size:10}},grid:{color:'#2a2a2a'}}
  }
});
const makeDataset = (data,color) => ({
  data, borderColor:color, backgroundColor:color+'22',
  borderWidth:2, pointRadius:2, fill:true, tension:0.3
});

let chartTemp, chartHum;

function initCharts(labels, temps, hums) {
  if (chartTemp) { chartTemp.destroy(); chartHum.destroy(); }
  chartTemp = new Chart(document.getElementById('chartTemp'), {
    type:'line',
    data:{labels, datasets:[makeDataset(temps,'#f44336')]},
    options:chartOpts('#f44336','°C')
  });
  chartHum = new Chart(document.getElementById('chartHum'), {
    type:'line',
    data:{labels, datasets:[makeDataset(hums,'#2196f3')]},
    options:chartOpts('#2196f3','%')
  });
}

// ── Carregar dias disponíveis ─────────────────────────────────
function loadAvailableDays() {
  fetch('/days')
    .then(r=>r.json())
    .then(days=>{
      const sel = document.getElementById('daySelect');
      sel.innerHTML = '';
      if (!days || days.length === 0) {
        sel.innerHTML = '<option>Sem dados ainda</option>';
        document.getElementById('histInfo').textContent =
          'Sem histórico — aguarda 10 minutos para o primeiro ponto.';
        return;
      }
      // Ordena do mais recente para o mais antigo
      days.sort((a,b)=>b.localeCompare(a));
      days.forEach(d=>{
        const opt = document.createElement('option');
        opt.value = d;
        // Converte "YYYY-MM-DD" para "DD/MM/YYYY"
        const parts = d.split('-');
        opt.textContent = parts[2]+'/'+parts[1]+'/'+parts[0];
        sel.appendChild(opt);
      });
      // Carrega o dia mais recente automaticamente
      loadSelectedDay();
    })
    .catch(()=>{
      document.getElementById('histInfo').textContent='Erro ao carregar dias.';
    });
}

// ── Download ─────────────────────────────────────────────────
function downloadDay() {
  const day = document.getElementById('daySelect').value;
  if (!day || day === 'Sem dados ainda') return;
  window.location.href = '/download?day=' + day;
}
function downloadAll() {
  window.location.href = '/download-all';
}

function loadSelectedDay() {
  const day = document.getElementById('daySelect').value;
  if (!day || day === 'Sem dados ainda') return;
  document.getElementById('histInfo').textContent = 'A carregar ' + day + '...';
  fetch('/history?day=' + day)
    .then(r=>r.json())
    .then(d=>{
      if (d.error) {
        document.getElementById('histInfo').textContent = d.error;
        return;
      }
      initCharts(d.labels, d.temps, d.hums);
      const parts = day.split('-');
      const dayFmt = parts[2]+'/'+parts[1]+'/'+parts[0];
      document.getElementById('histInfo').textContent =
        dayFmt + ' — ' + d.labels.length + ' pontos (intervalo: 10 min)';
    })
    .catch(()=>{
      document.getElementById('histInfo').textContent = 'Erro ao carregar dados.';
    });
}

// ── WebSocket ─────────────────────────────────────────────────
let wsConn, mistState = false;

function connect() {
  wsConn = new WebSocket('ws://' + location.hostname + '/ws');
  wsConn.onopen = () => {
    document.getElementById('wsdot').className = 'dot online';
    document.getElementById('wsstatus').textContent = 'Ligado';
  };
  wsConn.onclose = () => {
    document.getElementById('wsdot').className = 'dot offline';
    document.getElementById('wsstatus').textContent = 'Desligado — a reconectar...';
    setTimeout(connect, 3000);
  };
  wsConn.onmessage = (e) => {
    const d = JSON.parse(e.data);
    document.getElementById('temp').textContent    = d.temp.toFixed(1);
    document.getElementById('hum').textContent     = d.hum.toFixed(1);
    document.getElementById('water').textContent   = d.water;
    document.getElementById('waterBar').style.width = d.water + '%';
    document.getElementById('tempRange').textContent = d.tempMin+'C a '+d.tempMax+'C';
    document.getElementById('humRange').textContent  = d.humMin+'% a '+d.humMax+'%';
    document.getElementById('datetime').textContent  = d.date+'  '+d.time;

    const active = document.activeElement;
    const sliders = {
      tempMinSlider:[d.tempMin,'tempMinVal','°C'],
      tempMaxSlider:[d.tempMax,'tempMaxVal','°C'],
      humMinSlider: [d.humMin, 'humMinVal', '%'],
      humMaxSlider: [d.humMax, 'humMaxVal', '%']
    };
    Object.entries(sliders).forEach(([id,[val,lbl,unit]])=>{
      const el = document.getElementById(id);
      if (active!==el){el.value=val;document.getElementById(lbl).textContent=val+unit;}
    });

    mistState = d.mist;
    const badge = document.getElementById('mistBadge');
    const btn   = document.getElementById('mistBtn');
    if (d.mist){badge.textContent='ON';badge.className='badge on';btn.textContent='Desligar Manual';btn.className='toggle-btn on';}
    else{badge.textContent='OFF';badge.className='badge off';btn.textContent='Ligar Manual';btn.className='toggle-btn off';}

    const banner = document.getElementById('alertBanner');
    if (d.alertTemp||d.alertWater){banner.textContent='⚠️ '+d.alertMsg;banner.className='alert-banner show';}
    else{banner.className='alert-banner';}
  };
}

function send(obj){if(wsConn&&wsConn.readyState===1)wsConn.send(JSON.stringify(obj));}
function toggleMist()   {send({cmd:'setMist',   value:!mistState});}
function sendTempMin(v) {document.getElementById('tempMinVal').textContent=v+'°C';send({cmd:'setTempMin',value:parseInt(v)});}
function sendTempMax(v) {document.getElementById('tempMaxVal').textContent=v+'°C';send({cmd:'setTempMax',value:parseInt(v)});}
function sendHumMin(v)  {document.getElementById('humMinVal').textContent=v+'%'; send({cmd:'setHumMin', value:parseInt(v)});}
function sendHumMax(v)  {document.getElementById('humMaxVal').textContent=v+'%'; send({cmd:'setHumMax', value:parseInt(v)});}

connect();
</script>
</body>
</html>
)rawhtml";

// ── Setup ─────────────────────────────────────────────────────
void setup() {
  Serial.begin(115200);

  pinMode(RELAY_PIN, OUTPUT);
  mistOff();
  pinMode(WATER_PWR_PIN, OUTPUT);
  digitalWrite(WATER_PWR_PIN, LOW);

  // OLED
  Wire.begin(OLED_SDA, OLED_SCL);
  if (!display.begin(SSD1306_SWITCHCAPVCC, OLED_ADDRESS)) {
    Serial.println(F("OLED nao encontrado!"));
  } else {
    showBootScreen();
  }

  dht.begin();

  // LittleFS
  if (!LittleFS.begin(true)) {
    Serial.println(F("Erro ao montar LittleFS! A formatar..."));
    LittleFS.format();
    LittleFS.begin(true);
  }
  // Cria directório de dados se não existir
  if (!LittleFS.exists(DATA_DIR)) {
    LittleFS.mkdir(DATA_DIR);
  }
  Serial.println(F("LittleFS montado."));

  // Wi-Fi
  WiFi.begin(WIFI_SSID, WIFI_PASS);
  Serial.print(F("A ligar ao WiFi"));
  while (WiFi.status() != WL_CONNECTED) {
    delay(500); Serial.print('.');
  }
  Serial.println();
  Serial.printf("IP: %s\n", WiFi.localIP().toString().c_str());
  Serial.printf("MAC: %s\n", WiFi.macAddress().c_str());

  // Mostra IP no OLED
  display.clearDisplay();
  display.drawBitmap(2, 16, orchid_bmp, 32, 32, SSD1306_WHITE);
  display.setTextSize(1);
  display.setTextColor(SSD1306_WHITE);
  display.setCursor(40, 10); display.print(F("Orquidea IA"));
  display.setCursor(40, 22); display.print(F("v1.0"));
  display.drawLine(37, 8, 37, 50, SSD1306_WHITE);
  display.setCursor(40, 36); display.print(WiFi.localIP());
  display.display();
  delay(3000);

  // NTP — Portugal, muda automaticamente verão/inverno
  configTzTime(TZ_PORTUGAL, NTP_SERVER);

  // WebSocket
  ws.onEvent(onWsEvent);
  server.addHandler(&ws);

  // Rota principal
  server.on("/", HTTP_GET, [](AsyncWebServerRequest *req){
    req->send_P(200, "text/html", HTML_PAGE);
  });

  // Lista os dias disponíveis → JSON array de strings "YYYY-MM-DD"
  server.on("/days", HTTP_GET, [](AsyncWebServerRequest *req){
    req->send(200, "application/json", listAvailableDays());
  });

  // Histórico de um dia → /history?day=YYYY-MM-DD
  server.on("/history", HTTP_GET, [](AsyncWebServerRequest *req){
    String day = "";
    if (req->hasParam("day")) day = req->getParam("day")->value();
    if (day.length() == 0) {
      req->send(400, "application/json", "{\"error\":\"Parametro day em falta\"}");
      return;
    }
    req->send(200, "application/json", readDayHistory(day));
  });

  // Download CSV de um dia → /download?day=YYYY-MM-DD
  server.on("/download", HTTP_GET, [](AsyncWebServerRequest *req){
    String day = "";
    if (req->hasParam("day")) day = req->getParam("day")->value();
    if (day.length() == 0) {
      req->send(400, "text/plain", "Parametro day em falta");
      return;
    }
    char path[32];
    snprintf(path, sizeof(path), "%s/%s.csv", DATA_DIR, day.c_str());
    if (!LittleFS.exists(path)) {
      req->send(404, "text/plain", "Sem dados para este dia");
      return;
    }
    // Nome do ficheiro para download: orquidea-YYYY-MM-DD.csv
    String filename = "orquidea-" + day + ".csv";
    AsyncWebServerResponse *response = req->beginResponse(
      LittleFS, path, "text/csv"
    );
    response->addHeader("Content-Disposition",
      "attachment; filename=\"" + filename + "\"");
    req->send(response);
  });

  // Download de TODOS os dias num único CSV → /download-all
  server.on("/download-all", HTTP_GET, [](AsyncWebServerRequest *req){
    // Gera CSV completo em memória (até 1008 linhas ~ 40KB)
    String csv = "Data,Hora,Temperatura (C),Humidade (%)\n";
    File dir = LittleFS.open(DATA_DIR);
    if (dir && dir.isDirectory()) {
      // Coleta nomes para ordenar
      std::vector<String> files;
      File entry = dir.openNextFile();
      while (entry) {
        String name = entry.name();
        if (name.endsWith(".csv")) files.push_back(name);
        entry = dir.openNextFile();
      }
      std::sort(files.begin(), files.end());
      for (auto& fname : files) {
        String day = fname.substring(0, fname.length() - 4);
        String parts_y = day.substring(0,4);
        String parts_m = day.substring(5,7);
        String parts_d = day.substring(8,10);
        String dateFmt = parts_d + "/" + parts_m + "/" + parts_y;
        char fpath[32];
        snprintf(fpath, sizeof(fpath), "%s/%s", DATA_DIR, fname.c_str());
        File f = LittleFS.open(fpath, "r");
        if (!f) continue;
        while (f.available()) {
          String line = f.readStringUntil('\n');
          line.trim();
          if (line.length() == 0) continue;
          int c1 = line.indexOf(',');
          if (c1 < 0) continue;
          // linha: HH:MM,temp,hum  →  DD/MM/YYYY,HH:MM,temp,hum
          csv += dateFmt + "," + line + "\n";
        }
        f.close();
      }
    }
    AsyncWebServerResponse *response = req->beginResponse(
      200, "text/csv", csv
    );
    response->addHeader("Content-Disposition",
      "attachment; filename=\"orquidea-historico-completo.csv\"");
    req->send(response);
  });

  server.begin();
  Serial.println(F("Servidor web iniciado!"));
  Serial.println(F("Orquidea IA v1.0 pronta!"));

  lastReadMs    = millis();
  lastOledMs    = millis();
  lastHistoryMs = millis();
}

// ── Loop ──────────────────────────────────────────────────────
void loop() {
  ws.cleanupClients();
  unsigned long now = millis();

  if (now - lastReadMs >= READ_INTERVAL) {
    lastReadMs = now;
    readAndControl();
  }

  // Guarda ponto no histórico a cada 10 minutos
  if (now - lastHistoryMs >= HISTORY_INTERVAL_MS) {
    lastHistoryMs = now;
    updateTimeStrings();
    if (lastTemp != 0.0f || lastHumidity != 0.0f) {
      saveHistoryPoint(lastTemp, lastHumidity);
      pruneOldFiles();  // remove ficheiros com mais de 7 dias
    }
  }

  if (now - lastOledMs >= OLED_INTERVAL) {
    lastOledMs = now;
    updateDisplay();
  }
}
